In this post, you will learn how to take apart an HP Pavilion X360 notebook. You will know how to remove, replace the hard drive, battery, keyboard, RAM module, cooling fan, speakers, wireless card, palm rest and motherboard of HP Pavilion X360 notebook.

  1. A-Tech 8GB Module for HP Pavilion 11-n010dx x360 Laptop & Notebook Compatible DDR3/DDR3L PC3-Mhz Memory Ram (ATMS21X1) 5.0 out of 5 stars 1 $44.99.
  2. What is the maximum ram (memory) that the HP Pavilion x360 Convertible 15-cr0xxx can take? Is it a 260 or 288 pin memory card slot? Samsung 16GB DDR4 PC4.
Slots

Join us on the social network! Follow us on Facebook for all the latest repair news.

Remove all visible screws on the bottom case.

Remove the rubber mat with a screwdriver. You can see the hidden screws.
Unscrew all the screws.

Crucial Memory and SSD upgrades - 100% Compatibility Guaranteed for hp - compaq Pavilion x360 14-cd0077tu - FREE US Delivery.

Pry up and remove the bottom case.
Be careful, the USB board cable still connecting to the motherboard.

Hp pavilion 11 x360 ram slots

When the bottom case removed, you can get access to the internal components, including battery, hard drive, speaker, wireless card, CMOS battery, RAM, heat sink, cooling fan and motherboard.

Remove all screws securing the battery.
Disconnect the battery connector from the motherboard. You can remove the battery.

The laptop comes with a 7.6V, 29wh Li-ion battery. HP model: 751681-421.

Remove all screws securing the hard drive and disconnect the SATA cable from the motherboard.

HP Pavilion X360 features a Western Digital 500GB hard drive, HP model: 726835-0001.

Hp Pavilion X360 Convertible Ram Slots

Remove four screws securing the speaker modules (left and right).
Disconnect two speaker cables from the motherboard.
You can remove the speaker modules.

Here’s speaker module.

Separate the clips.

The memory module will pop up.

It comes with an SK Hynix 4GB DDR3L-1600MHz RAM, HP P/N: 591740-005.

Hp pavilion x360 slot ram 8gb

Remove two screws and unplug two wireless cables, you can remove the wireless card.

Hp Pavilion X360 Slot Ram Upgrade

HP Pavilion X360 wireless card, HP P/N: 733475-005.

Remove all the screws securing the cooling fan and heat sink.

The cooling fan coming from SUNON

In the next step, I will remove the motherboard.

Remove all cables connecting to the motherboard.

Remove all screws securing the motherboard.

Hp Pavilion X360 Slot Ram Specs

HP Pavilion X360 motherboard

Now you can access the touchpad and keyboard.
